| 选择 | 询价 | 轴承型号 | 尺寸 | ||
|---|---|---|---|---|---|
| d (mm) | D (mm) | B (mm) | |||
| F3-8M | 3 | 8 | 3.5 | ||
| F4-10M | 4 | 10 | 4 | ||
| F4-9M | 4 | 9 | 4 | ||
| F5-12M | 5 | 12 | 4 | ||
| F6-12M | 6 | 12 | 4.5 | ||
| F6-14M | 6 | 14 | 5 | ||
| F7-13M | 7 | 13 | 4.5 | ||
| F7-17M | 7 | 17 | 6 | ||
| F8-16M | 8 | 16 | 5 | ||
| F8-19M | 8 | 19 | 7 | ||
| F9-20M | 9 | 20 | 7 | ||
| F10-18M | 10 | 18 | 5.5 | ||
| 51100 | 10 | 24 | 9 | ||
| 51200 | 10 | 26 | 11 | ||
| 51101 | 12 | 26 | 9 | ||
| 51201 | 12 | 28 | 11 | ||
| 51102 | 15 | 28 | 9 | ||
| 51202 | 15 | 32 | 12 | ||
| 51103 | 17 | 30 | 9 | ||
| 51203 | 17 | 35 | 12 | ||
| 51104 | 20 | 35 | 10 | ||
| 51204 | 20 | 40 | 14 | ||
| 51105 | 25 | 42 | 11 | ||
| 51205 | 25 | 47 | 15 | ||
| 51305 | 25 | 52 | 18 | ||
| 51405 | 25 | 60 | 24 | ||
| 51106 | 30 | 47 | 11 | ||
| 51206 | 30 | 52 | 16 | ||
| 51306 | 30 | 60 | 21 | ||
| 51406M | 30 | 70 | 28 | ||
